BESCHICHTUNGSKATALOG

Hier finden Sie ausführliche Informationen und Eignungshinweise zu allen Beschichtungen, die wir in unserer Werkzeugfertigung einsetzen. Bei Fragen stehen wir Ihnen gerne jederzeit zur Verfügung: office@wedco.at

WEPA


Coating material: AlTiN-based
Delivery time: 2 weeks
Layer thickness/side: 2-5µm
Maximum temperature resistance: 1000°C
Microhardness HV (0.05): 3500 HV
Application: Drilling
Suitable for the following material groups: Buchstaben mit unterschiedlichem Hintergrund
P
K
M
S

WEFU


Coating material: TiAlN
Delivery time: 2-5 days
Layer thickness/side: <Ø3:1-2,5µm; >Ø3: 2-5µm
Maximum temperature resistance: 900°C
Microhardness HV (0.05): 3300 HV
Application: Drilling
Suitable for the following material groups: Buchstaben mit unterschiedlichem Hintergrund
P
K
M

WEAD


Coating material: AlCrN-basierend
Delivery time: 1 week
Layer thickness/side: <Ø6:1-2,5µm; >Ø6: 2-5µm
Maximum temperature resistance: 1100°C
Microhardness HV (0.05): 3300 HV
Application: Milling
Suitable for the following material groups: Buchstaben mit unterschiedlichem Hintergrund
P
K
H

WEAC


Coating material: AlCrN-basierend
Delivery time: 2-5 days
Layer thickness/side: <Ø3:1-2,5µm; >Ø3: 2-5µm
Maximum temperature resistance: 1100°C
Microhardness HV (0.05): 3200 HV
Application: Milling, drilling
Suitable for the following material groups: Buchstaben mit unterschiedlichem Hintergrund
P
K
M

WETS


Coating material: AlTiSiN-based
Delivery time: 1 week
Layer thickness/side: <Ø3:1-2,5µm; >Ø3: 2-5µm
Maximum temperature resistance: 1100°C
Microhardness HV (0.05): 3800 HV
Application: Milling, drilling
Suitable for the following material groups: Buchstaben mit unterschiedlichem Hintergrund
P
K
M
S
H

WEZY


Coating material: ZrCN
Delivery time: 5 days
Layer thickness/side: 1-4µm
Maximum temperature resistance: 600°C
Microhardness HV (0.05): 2800 HV
Application: Milling, drilling
Suitable for the following material groups: Buchstaben mit unterschiedlichem Hintergrund
M
S
N

WEXX


Coating material: TiALN
Delivery time: 2 days
Layer thickness/side: 2-4µm
Maximum temperature resistance: 1000°C
Microhardness HV (0.05): 3500 HV
Application: Drilling
Suitable for the following material groups: Buchstaben mit unterschiedlichem Hintergrund
P
K

WETN


Coating material: TiN
Delivery time: 1 week
Layer thickness/side: 1-4µm
Maximum temperature resistance: 500°C
Microhardness HV (0.05): 2300 HV
Application: Milling, drilling
Suitable for the following material groups: Buchstaben mit unterschiedlichem Hintergrund
P
K

WESR


Coating material: AlTiCrN
Delivery time: 1 week
Layer thickness/side: 2-4µm
Maximum temperature resistance: 800°C
Microhardness HV (0.05): 3000 HV
Application: Milling
Suitable for the following material groups: Buchstaben mit unterschiedlichem Hintergrund
P
K

WEHA


Coating material: AlTiSi-based
Delivery time: 2 weeks
Layer thickness/side: 2-4µm
Maximum temperature resistance: 1100°C
Microhardness HV (0.05): 3800 HV
Application: Milling, drilling
Suitable for the following material groups: Buchstaben mit unterschiedlichem Hintergrund
H

WEEX


Coating material: AlCrN-basierend
Delivery time: 1 week
Layer thickness/side: 2-4µm
Maximum temperature resistance: 1100°C
Microhardness HV (0.05): 3400 HV
Application: Milling, drilling
Suitable for the following material groups: Buchstaben mit unterschiedlichem Hintergrund
P
K
M

WECX


Coating material: AlTiXN
Delivery time: 2 days
Layer thickness/side: 2-4µm
Maximum temperature resistance: 900°C
Microhardness HV (0.05): 3500 HV
Application: Milling
Suitable for the following material groups: Buchstaben mit unterschiedlichem Hintergrund
P
K

WELC


Coating material: ta-C (DLC)
Delivery time: 3 weeks
Layer thickness/side: 0,5-1µm
Maximum temperature resistance: 550°C
Microhardness HV (0.05): 6000-8000 HV
Application: Milling, drilling
Suitable for the following material groups: Buchstaben mit unterschiedlichem Hintergrund
N

P
Steel <52 HRC

M
Stainless steel <52 HRC

K
Cast iron

N
Non-ferrous metals, AL alloys
S
Superalloys and titanium

P
Hardened steel <70 HRC
